SPECIFICATIONS

Battery: Lithium-Ion ALTIS PowerPack

Battery capacity: 35 Ah

Braking System: Disc Brake

Chain: 428H

Charging input: AC110V/112V12.5A

Cooling: Air cooled

Electric motor: 98V - Hairpin motor

Frame Material: Aluminum

Gears: 3 Speed

Max. power: 25 kW

Motor position: Central Motor

Place of Origin: China

Suspension travel (rear): 85 mm with linkage

Tire Width: 26*2.6"

Torque: 601NM,601 Nm (443 ft-lbs)

Voltage: 98v

Wheel Size: 19''

Wheels: Spoked wheels with aluminum rims

Product Description

CHASSIS

* Weight (with battery): 88 kg
* Wheelbase: 1285 mm
* Front brake disc diameter: 260 mm
* Rear brake disc diameter: 220 mm
* Chain: 428H
* Frame design: Aluminium alloy forging
* Ground clearance: 300m
* Seat height: 840 mm
* Steering head angle: 26 °
* Suspension travel (front): 200 mm
* Suspension travel (rear): 85 mm with linkage
* Rear Wheel travel: 200mm with linkage
* Wheels: Spoked wheels with aluminum rims

Motor

* Max. power: 23 kW (31HP)
* Torque: 601 Nm (443 ft-lbs)
* Battery: Lithium-Ion ALTIS PowerPack
* Battery capacity: 35 Ah
* Charging input: AC110V/112V12.5A
* Charging time 20%-100%: 180 min.
* Charging time 20%-80%: 120 min.
* Cooling: Air cooled
* Energy content: 3.402 kWh
* Electric motor: 98V - Hairpin motor

MODEL HIGHLIGHTS

1)MODEL HIGHLIGHTS 97.2V35Ah (3402Wh) 2)Samsung 50S battery Cells (Greenway Battery Pack) Charging time (20% - 80%): 2 Hours

3)23kw(31HP) peak Hairpin Motor (Automotive standard)

4)Adjustable off-road air-spring suspension

5)3.5" TFT display with NFC feature

6)5levels of regenerative braking

7) Headlight & Taillight (w/brake light) switch 8)Heavy duty disc brake CST off-road tires

Specification

item	value
Model	2026 SIGMA MX
Max. Speed	> 80km/h
Place of Origin	jiangsu
Motor	Other
Brand Name	Altis
Model Number	sigma
Max. power	23 kW (31HP)
Torque	601 Nm (443 ft-lbs)
Battery	Lithium-Ion ALTIS PowerPack
Battery capacity	35 Ah
Charging input	AC110V/112V12.5A
Chain	428H
Electric motor	98V - Hairpin motor
Cooling	Air cooled
Wheels	Spoked wheels with aluminum rims
Suspension travel (rear)	85 mm with linkage
